Parksafe Ford Custom Brake Light Camera PSC41

Description

Parksafe Ford Custom Brake Light Camera PSC41

Description:

• Ford Transit Custom > May 2016 (LED Type Ford 2009953)  Replaces Ford Part Number 1816872

Specification:

• Image Type – 1/3” Colour CMOS
• Night vision With IR lamp
• TV System – PAL/NTSC with Switchable
• Lens Angle (Deg.) – 120 degree
• IP Rating – IP69K
• Vibration Rate – 10G
• Connector 4P BMW to 4P lock connector
• Effective Pixels N: 510×492 pixels P: 500×582 pixels
• Horizontal Resolution 700TVL
• White Balance Auto White Balance (Auto)
• B.L.C Back light Compensation (Auto)
• Minimum Illumination 0Lux (LED ON)
• S/N Ratio 48dB
• Electronic Shutter 1/60~1/100,000 Sec
• Power consumption <3W
• Built-in Lens f: 2.8mm
• Power Consumption DC 12V (+/-10%)
• Audio without
• Operation Temperature -30℃~+70℃.RH95% Max
• Storage Temperature -40℃~+80℃.RH95% Max
• 2 Years Warranty

Certificates: FCC, CE, E-mark, ISO9001, TS16984 & RoHS • 4 Pin connector 15m cable

Code: CAMINTER14 Ford Sync 3 Camera Interface Available For Screen Size: 8”
